Faro
Extended scanning - 330m range
The Focus3D X 330 can scan objects up to 330 meters away. Large buildings, land-site excavations and vast terrains can be surveyed with fewer scans, thus resulting in quicker project scanning completion.
Easy positioning - integrated GPS receiver
With its integrated GPS receiver, the laser scanner is able to correlate individual scans in post-processing making it ideal for surveying based applications.
Outdoor scanning capability
The Focus3D X 330 now is able to perform fast and highly precise scanning in direct sunlight
Low noise performance
The new FARO Focus3D X 330 delivers extraordinary scan data quality at extended range with very low noise.
Wireless LAN
WLAN remote control permits you to start, stop, and view scans at a distance.
Extended outdoor scanning in full sunlight
The new FARO Focus3D X 330 a high-speed 3D scanner with extra-long range. The Focus3D X advances into entirely new dimensions: it can scan objects up to 330 meters away even in direct sunlight.
With its integrated GPS receiver, the laser scanner is able to correlate individual scans in post-processing making it ideal for surveying based applications.
With its increased range and scan quality, the FARO Focus3D X 330 considerably reduces the effort involved in measuring and post-processing. The 3D scan data can easily be imported into all commonly used software solutions for accident reconstruction, architecture, civil engineering, construction, forensics, industrial manufacturing and land surveying. Distance dimensions, area and volume calculations, analysis and inspection tasks and documentation can thus be carried out quickly, precisely and reliably.
Benefits
The new FARO Focus3D X 330 is the leading tool for surveying and 3D documentation.
Scanning range - 330m, integrated GPS, the possibility to work in direct sunlight as well as the specially for the scanner designed protection cover make it a ideal tool for outdoor environments.
Specifications:
Ranging Unit:
Unambiguity Interval: By 122 till 488 Kpts/sec at 614m; by 976 Kpts/sec at 307m
Range Focus3D X 330: 0.6m – 330m indoor or outdoor with upright incidence to a 90% reflective surface
Measurement Speed (pts/sec): 122,000 / 244,000 / 488,000 / 976,000
Ranging Error1
: ±2mm
Color Unit:
Resolution: Up to 70 megapixel color
Dynamic Color Feature: Automatic adaption of brightness
Parallax: Co-axial design
Deflection Unit:
Vertical Field of View (vertical/horizontal): 300° / 360°
Step Size (vertical/horizontal): 0.009° (40,960 3D-Pixel on 360°) / 0.009° (40,960 3D-Pixel on 360°)
Max. Vertical Scan Speed: 5,820rpm or 97Hz
Laser (Optical Transmitter):
Laser Class: Laser class 1
Wavelength: 1550nm
Beam Divergence: Typical 0.19mrad (0.011°) (1/e, halfangle)
Beam Diameter at Exit: Typical 2.25mm (1/e)
Data Handling and Control:
Data Storage: SD, SDHC™, SDXC™; 32GB card included
Scanner Control: Via touch-screen display and WLAN
New WLAN Access: Remote control, scan visualization are possible
on mobile devices with Flash
Multi-Sensor:
Dual Axis Compensator: Levels each scan with an accuracy of 0.015° and a range of ±5°
Height Sensor: Via an electronic barometer the height relative to a fixed point can be detected
and added to a scan
Compass: Electronic compass gives the scan an orientation. A calibration feature is included.
GPS: Integrated GPS receiver
INCLUDED :
Faro Focus3D X330 3D Laser Scanner [BC# -L/T*]
2 batteries
1 AC/DC charger
1 car charger for cigarette lighter
1 carbon tripod with accessories
1 scanner quick-mount adapter
1 SD card 32GB
1 tripod base with 5/8" thread
1 protective cover
1 trolley transport case
Also you can check product : USED GeoSlam Zeb Revo RT Handheld 3D Scanner
The 3D scan data can easily be imported into all commonly used software solutions for accident reconstruction, architecture, civil engineering,construction, forensics or industrial manufacturing.
With a battery runtime of 4.5 hours, the laser scanner has also a high level
of flexibility and endurance. The Focus’ light weight, small size and SD-card
makes the scanner truly mobile.
SPECS :
Ranging unit
Unambiguity interval: >130m
Range Focus3D X 130: 0.6m – 130m indoor or outdoor with upright incidence to a 90% reflective surface
Measurement speed (pts/sec): 122,000 / 244,000 / 488,000 / 976,000
Ranging error1: ±2mm
Colour unit
Resolution: Up to 70 megapixel colour
Dynamic colour feature: Automatic adaption of brightness
Parallax: Co-axial design
Deflection unit
Field of view (vertical/horizontal): 300° / 360°
Step size (vertical/horizontal): 0.009° (40,960 3D-Pixel on 360°) / 0,009° (40.960 3D-Pixel on 360°)
Max. vertical scan speed: 5.820rpm or 97Hz
Laser (optical transmitter)
Laser class: Laser class 1
Wavelength: 1550nm
Beam divergence: Typical 0.19mrad (0,011°) (1/e, halfangle)
Beam diameter at exit: Typical 2.25mm (1/e)
Data handling and control
Data storage: SD, SDHC, SDXC; 32GB card included
Scanner control: Via touchscreen display and WLAN
New WLAN access: Remote control, scan visualisation are possible on mobile devices with Flash®
Multi-Sensor
Dual axis compensator: Levels each scan: Accuracy 0.015°; Range ± 5°
Height sensor: Via an electronic barometer the height relative to a fixed point can be detected and added to a scan.
Compass4: The electronic compass gives the scan an orientation. A calibration feature is included.
GPS: Integrated GPS receiver
Power supply voltage: 19V (external supply) / 14.4V (internal battery)
Power consumption: 40W and 80W (while battery charges)
Battery life: 4.5 hours
Ambient temperature: 5° – 40°C
Humidity: Non-condensing
Cable connector: Located in scanner mount
Weight: 5.2kg
Size: 240 x 200 x 100mm
Maintenance / calibration: Annual
Included:
FARO Focus3D-X130, with GPS, Compass, Altimeter (barometer), Dual-axis Compensator and WLAN
PowerBlock Battery
Power Supply
32GB SD Card
SD Card Reader
SD Card Cover
Rugged Transport Case
License SCENE Software
1 Year Maintenance Contract for SCENE Software
Gitzo Mountaineer carbon fiber tripod
Rugged Transport Case
Also you can check product : USED Faro Focus3D X330 Laser Scanner - Fresh Calibrated
The ultra-portable FARO Focus S 150 Plus laser scanner allows you to quickly and precisely measure objects and buildings. It digitizes building facades, complex structures, production and supply sites, accident scenes and large-scale construction elements, provides realistic and detailed results with a range of 150 meters per scan. Capturing the measurements of a large building, facility, or crash/crime scene with conventional documentation methods can take days or weeks, and even then, the data might contain errors or missing details.
Power supply voltage: 19V (external supply) 14.4V (internal battery)
Power consumption: 15W idle, 25W scanning,80W charging
Battery service life: 4.5 hours
Operating temperature: 5° – 40°C
Extended operating temperature: -20° – 55°C
Storage temperature: -10° – 60°C
Ingress Protection: IP54
Humidity: Non-condensing
FEATURES :
The Focus S PLUS Laser Scanner boasts a lightweight, compact design, with an impressive 4.5-hour battery runtime per charge, ensuring its true mobility for quick, secure, and dependable scanning.
It is rated IP54, making it resistant to dirt, dust, fog, rain, and other outdoor elements often encountered in challenging scanning environments.
The laser scanning solution supports remote scanning and offers virtually limitless data sharing via SCENE Webshare Cloud, enhancing its overall mobility.
It delivers scan results that are both realistic and intricately detailed, covering a range of 150m per scan, while its intuitive touch-screen interface simplifies operation.
Additionally, the ultra-portable FocusS 150 is capable of facilitating swift, uncomplicated, and extremely precise measurements of various objects and structures.
Its built-in 8-megapixel HDR camera effortlessly captures detailed imagery, providing a natural color overlay to the scan data, even in extreme lighting conditions.
Technical Data :
Range: 0.6 – 150m
High Dynamic Range (HDR) Photo Recording 2x/3x/5x
Measurement Speed: up to 976,000 points/second
Ranging Error: ± 1mm
Sealed Design – Ingress Protection (IP) Rating Class 54
On-site Compensation
Accessory Bay
Angular Accuracy: 19 arc sec for vertical/horizontal angles
Integrated Colour Camera: Up to 165 mio. pixel
Laser Class: Laser class 1
Weight: 4.2kg
Multi-Sensor: GPS, Compass, Height Sensor, Dual Axis Compensator
Size: 230 x 183 x 103mm
Scanner Control: via Touch Screen Display and WLAN
Includes:
FARO Focus S 150
Calibration certificate
2 batteries
Charger
32GB SD / USB adapter
Carbon tripod
Tripod adapter
Scene software dongle
Transport case
Also you can check product : USED Faro Focus M70 3D Laser Scanner With Gitzo Tripod
FEATURES
Accuracy and range
The Focus Laser Scanner Series provides the highest accuracy and ranges up to 350m by using a combination of the most advanced sensor technologies.
Adaptable and quick
Document any project site or scene, whether indoors or outdoors, in bright sun or complete darkness in minutes. Customize settings to adapt to any scene and capture up to 976,000 points/sec.
IP Rating – Class 54 and extended temperature range
With the sealed design, the Focus devices are certified with the industry-standard Ingress Protection (IP) Rating and classified in class 54 against environmental influences. In addition, there is a scanning challenging temperature conditions due to an extended temperature range.
On-Site compensation
With the on-site compensation functionality, users can verify and adjust the Focus compensation on-site or in the office immediately before scanning, ensuring high-quality scan data and traceable documentation. A comprehensive compensation document is automatically generated.
On-Site registration
During on-site data capture, the laser scanner immediately transmits scanned data wirelessly to FARO SCENE for real-time scan processing and registration, providing efficiency and time savings.
Scan Group feature (Rescanning of Distant Targets)
The Scan Group feature identifies multiple areas to be rescanned with higher resolution to either perform accurate target detection or to capture smaller areas of interest with greater detail.
Retake photos option
No need to redo the entire scans. Select the images to retake the photos in seconds.
Integrated accessory bay
With this future-proof interface, users can connect additional accessories to the scanner, which offers an option for user-specific customization.
Lightweight and easily portable
Weighs only about 4.2 kg the Focus Laser Scanner is extremely mobile and portable.
HDR photo overlay
With the Focus HDR functionality, challenges like lighting situations will never subtract users’ scan results. Predefined HDR profiles increase the picture quality which is recorded in very bright or dark environments.
Digital hashing function
The automatic digital hashing feature provides encrypted security to all raw scans by hashing data at the time of capture. Use the Scan Verification Tool to ensure that the scan files have not been altered in any way and data is unchanged since first captured.
Status indicator
The visual indicator provides the operator the status of the laser scanner for improved on-site safety.
SPECS :
Ranging unit
Unambiguity interval 614m for 122 to 488 kpts/s
307m for 976 kpts/s
Reflectivity 90% (white) 10% (dark-gray) 2% (black)
Range 0.6-150 m 0.6-150 m 0.6-50 m
Ranging noise @10m @10m - noise reduction @25m @25m - noise reduction
90% reflectivity 0.3mm 0.15mm 0.3mm 0.15mm
10% reflectivity 0.4mm 0.2mm 0.5mm 0.25mm
2% reflectivity 1.3mm 0.65mm 2mm 1mm
Measurement speed (pts/sec): 122,000 / 244,000 / 488,000 /
976,000
Ranging error ±1mm
Angular accuracy 19 arcsec for vertical/horizontal angles
3D position accuracy 10m: 2mm / 25m: 3.5mm
Color unit
Resolution: Up to 165 megapixel color
High Dynamic Range (HDR) : Exposure Bracketing 2x, 3x, 5x
Parallax Minimized due to co-axial design
Deflection unit
Field of view (vertical/horizontal): 300° / 360°
Step size (vertical/horizontal) 0.009° (40,960 3D-Pixel on 360°) /
0.009° (40,960 3D-Pixel on 360°)
Max. vertical scan speed 97Hz
Laser (optical transmitter)
Laser class: Laser class 1
Wavelength 1550nm
Beam divergence: 0.3mrad (1/e)
Beam diameter at exit: 2.12mm (1/e)
Data handling and control
Data storage SD, SDHC™, SDXC™; 32GB card
Scanner control: Via touchscreen display and
WLAN connection. Accsess by
mobile devices with HTML5
Interface Connection
WLAN 802.11n (150Mbit/s), as Access
Point or client in existing networks
Integrated Sensors
Dual axis compensator Performs a leveling of each scan
with an accuracy of 19 arcsec
valid within ±2°
Height sensor: Via an electronic barometer the
height relative to a fixed point
can be detected and added to
a scan.
Compass The electronic compass gives the
scan an orientation
GNSS Integrated GPS & GLONASS
On-site Compensation Creates a current quality report and provides the option to improve the devices compensation automatically
Accessory Bay The accessory bay is located on top of the laser scanner and is used to connect versatile accessories to the scanner.
GENERAL
Power supply voltage: 19V (external supply)
14.4V (internal battery)
Power consumption 15W idle, 25W scanning,
80W charging
Battery service life: 4.5 hours
Operating temperature: 5° - 40°C
Extended operating temperature 20° - 55°C
Storage temperature: -10° - 60°C
Ingress Protection IP54
Humidity Non-condensing
Weight incl. battery 4.2kg
Size 230 x 183 x 103mm
Maintenance / calibration: Annual
Includes:
Faro S150 Focus 3D Laser Scanner
Three Battery Packs
Faro Power Dock charging station
Tripod adapters
Gitzo Carbon fiber Tripod
Six Koppa Scanning Spheres with case
Six Koppa Sphere tripods
Faro Scanner Case
Faro Scanner Backpack
Also you can check product : USED Faro Focus S150 Plus 3D Laser Scanner - Calibrated
Xtra accuracy: The verifiable accuracy of 1mm enables you to carry out highly challenging scanning projects.
Optional on-site calibration: The device can be easily calibrated on-site ensuring high quality data. A PDF report with key data permits maximum and verifiable confidence in the acquired data.
Automatic flash: The new auto mode automatically activates and de-activates the built-in LED light depending on the existing light conditions.
Real-time point cloud visualization: The real-time point cloud visualization supports the intuitive data acquisition, even for untrained operators.
Up to 8m³ scanning volume: The extensive scan volume boosts productivity by reducing scan time.
Best point filter: The new best point filter minimizes the noise and allows to get optimum data quality.
Specs :
Range: 0.5 - 3m
Resolution @ 0.5m distance
Lateral: 0.2mm - 1mm
Depth: 0.2mm
3D point accuracy1 ≤1.0mm
Typical lateral accuracy2 ≤1mm
Single image point density
Up to 45,000 points/m² in 0.5m distance
Up to 10,500 points/m² in 1m distance
Recorded 3D points3: Up to 88,000 points/s, point cloud density increases with time
Typical Noise (rms)
0.7mm @ 0.5m distance
0.75mm @ 1m distance
2.5mm @ 2m distanc
5mm @ 3m distance
Best point filter4
Noise reduction of typically 40% when scanning the same object from different distances
Eye safety: Class 1 laser
Lighting conditions: Up to 10,000 Lux
Light source: Inbuilt auto LED flash
Scan volume: 8.1m³
Typical field of view (HxW)
450mm x 530mm @ 0.5m
930mm x 1,100mm @ 1m
1,800mm x 2,000mm @ 2m
2,600mm x 2,900mm @ 3m
Typical angular field of view (HxW)
45°x56° @ 0.5m
45°x59° @ 1m
49°x54° @ 2m
49°x52°@ 3m
Exposure time 0.02ms - 10ms (autoexposure)
Texture color: 24bit
Dimensions: 260mm x 310mm x 105mm
Connectivity: USB 3.0
Weight: 0.98kg
Power supply: 5W, USB 3.0-powered
IP rating: IP 52*
Calibration Optional in-field user calibration with supplied calibration plate.
Operating temperature range: 0- - 40°C
Operating humidity range: Non-condensing
Laser power: max. 800mW
Duration of pulse <= 10ms
Wavelength 798-821nm
Includes :
Faro Freestyle-3D X Scanner
Tablet Surface Pro 3 (Microsoft)
Calibration certificate
MicroSD Card and USB stick
Calibration Plate
Cleaning Kit
Rugged Transport Case
Aslo you can check product : USED Faro Focus S120 3D Laser Scanner - Calibrated
Faro S70 Scanner Features
Accuracy
Highest accuracy and range by using a combination of the most advanced sensor technologies.
Rescanning of Distant Targets
The Scan Group feature identifies multiple areas to be rescanned with higher resolution to either perform accurate target detection or to capture smaller areas of interest with greater detail.
IP Rating 54 and Extended Temperature Range
With the sealed design and certified with the industry standard Ingress Protection (IP) Rating, IP54, the Focus can be used in wet weather conditions at temperatures from -20°C to 55°C8
Compact and Portable
Focus Laser Scanners are the smallest and lightest devices in their performance class.
On-Site Compensation (Focus S and S Plus models only)
With the on-site compensation functionality, users can verify and adjust the FocusS compensation immediately before scanning, ensuring high-quality scan data and traceable documentation.
On-Site Registration (Focus S and S Plus models only)
During on-site data capture, the laser scanner immediately transmits scan data wirelessly to FARO SCENE for real-time scan processing and registration, providing efficiency and time savings.
Benefits
Confidence in documented data-quality by traceable calibration and market-leading on-site compensation.
Mount the FocusS scanner in an inverted position, such as under a ceiling of a hall.
The Focus Laser Scanner portfolio offers the most economic 3D scanning solution for all requirements and budgets.
Minimum training effort is ensured by the intuitive and easy to operate touch-screen interface as well as hands-on and online tutorials.
Efficient integration into existing software infrastructures and workflows are provided by interfaces to various standard CAD systems.
Offers the highest accuracy and range. It’s also compact and portable, being one of the smallest and lightest devices in its performance class.
If you’re after efficiency and time saving, the laser scanner immediately transmits scan data wirelessly to FARO SCENE for real-time processing and
SPECS :
Application
Main users
Android/iOS
Main applications
Inspection, Settlement Control, Reverse Engineering, Scan to BIM in Architecture, Engineering, Construction, Public Safety and Forensics or Product Design.
Peripherals
User interface
Via touchscreen display and WLAN connection. Access by mobile devices with HTML5
Specifications
Data Storage: SD, SDHC™, SDXC™; 256GB card
Additional sensors
Height Sensor, Compass, Integrated GPS and GLONASS
Registration/orientation methods
The electronic compass gives the scan an orientation. A calibration feature is included.
Operation Characteristics
Operating temperature: min. [°C]
5 - 40 normal | -20 - 55 extended | -10 - 60 storage
Operating temperature: max. [°C]
40
Humidity range [%]
non-condensing
Internal Camera
Y
IP Rating
54
Dual Axis Compensation
Y
Control panel built in
Y
Scanning Characteristics
Max. vertical field of view [deg]
300
Max. horizontal field of view [deg]
360
Min. horizontal step size [deg]
0.009
Min. vertical step size [deg]
0.009
Beam deflection mechanism
Rotating Mirror
Max. measurement rate [kHz]
97
Software Functionality
Real time visualization during scanning
Y
Geo-referencing
Y
Laser Ranger
Wavelength [nm]
1550
Laser safety classification
1
Min. Range [m]
0.6
Max. Range [m]
70
Beam diameter at exit [mm]
2.12
Beam divergence [mrad]
0.3
Range measurement principle
pulse
Power
Battery type
19 V external - 14.4 V internal
Scan time per battery [h]
4.5
General
Height [m]
23
Depth [m]
18.3
Width [m]
10.3
Total Weight [kg]
4.2
Includes:
1x FocusS 70, with HDR photography, with GPS, compass, altimeter (barometer), dual-axis compensator, WLAN, IP rating 54,
1x Battery Power Block,
1x Battery Power Dock,
1x 90W Power Supply,
1x Optic Cleaning Fluid,
3x Optic Cleaning Tissues,
1x 32GB SD card,
1x SD card reader,
1x SD card cover,
1x rugged transport case,
calibration certificate,
Also you can check product : USED Faro Freestyle3D Handheld Scanner - Calibrated
Specs :
Measurement speed (pts/sec): 122,000 / 244,000 / 488,000 / 976,000
Ranging error4: ±1mm
Angular accuracy5 19 arcsec for vertical/horizontal angles
3D position accuracy6 10m: 2mm / 25m: 3.5mm
Color Unit
Resolution: Up to 165 megapixel color
High Dynamic Range (HDR): Exposure Bracketing 2x, 3x, 5x
Parallax: Minimized due to co-axial design
Deflection Unit
Field of view (vertical7/horizontal): 300° / 360°
Step size (vertical/horizontal): 0.009° (40,960 3D-Pixel on 360°) /
0.009° (40,960 3D-Pixel on 360°)
Max. vertical scan speed: 97Hz
Laser (Optical Transmitter)
Laser class: Laser class 1
Wavelength: 1550nm
Beam divergence: 0.3mrad (1/e)
Beam diameter at exit:: 2.12mm (1/e)
Data Handling and Control
Data storage: SD™, SDHC™, SDXC™; 32GB card
Scanner control: Via touchscreen display and WLAN connection. Access by mobile devices with HTML5
Interface Connection
WLAN: 802.11n (150Mbit/s), as Access Point or client in existing networks
Integrated Sensors
Dual axis compensator: Performs a leveling of each scan with an accuracy of 19 arcsec valid within ±2°
Height sensor: Via an electronic barometer, the height relative to a fixed point can be detected and added to a scan.
Compass8: The electronic compass gives the scan an orientation
GNSS: Integrated GPS & GLONASS
On-site Compensation Creates a current quality report and provides the option to improve the device's compensation automatically.
Accessory Bay The accessory bay is located on top of the laser scanner and is used to connect versatile accessories to the scanner.
General
Power supply voltage: 19V (external supply) 14.4V (internal battery)
Power consumption: 15W idle, 25W scanning, 80W charging
Battery service life: 4.5 hours
Operating temperature: 5° - 40°C
Extended operating temperature9 -20° - 55°C
Storage temperature: -10° - 60°C
Ingress Protection: IP54
Humidity Non-condensing
Weight incl. battery: 4.2kg
Size: 230 x 183 x 103mm
Maintenance / calibration: Annual
In The Box :
1 x Faro Focus S350 Laser Scanner
1 x Faro Focus Peli Case
2 x Faro Power Block, Focus M/S
1 x Faro Power Dock, Focus M/S
1 x Faro Standard Power Supply for Focus M/S
1 x Faro SD Card, 32GB
1 x Faro SD Card Case
1 x Faro SD Card Reader, Focus3D
1 x Faro Quick Release M & S Series
1 x Benro Laser Scanner Carbon Tripod for FARO Focus
Also you can check product : USED Leica ScanStation P30 High Definition 3D Laser Scanner
Features
SHORT-RANGE SCANNING - UP TO 70M: The FocusM 70 can record data up to 70 meters making it ideal for short-range measurements and small area applications
COMPACT AND PORTABLE: The FocusM 70 has the size of only 230 x 183 x 103mm and a weight of just 4.2kg. The device is provided with a waterproof transportation and ergonomic carrying case for true portability
HDR PHOTO OVERLAY: The HDR camera captures detailed imagery easily while providing a natural color overlay to the scan data captured under extreme brightness gradients
BEST VALUE FOR MONEY: The FocusM 70 is a professional grade scanner with the highest return on investment in the market
IP RATING - CLASS 54: With the sealed design, the FocusM 70 is certified with the industry standard Ingress Protection (IP) Rating and classified in class 54 against environmental influences.
TEMPERATURE: Extended temperature range allows scanning in challenging environments - take your Focus M to the desert or run a project in Antarctica
Benefits
Scanning in rough environments while providing protection from dust, debris and water splashes
The Focus M 70 delivers a full scanning workflow at best return on invest in the market
Achieve confidence in scan results by using award winning FARO quality
Maintain familiar workflows through freedom of choice in processing scan data in various software packages
Easily navigate the scanner controls using the large and luminous touch-screen
SPECS :
Ranging unit
Range Focus M 70:
0.6m - 70m 90% (white)
0.6m - 70m 10% (dark-gray)
0.6m - 50m 2% (black)
Measurement speed (pts/sec):
122,000 / 244,000 / 488,000
Ranging error
±3mm
Colour unit
Resolution:
Up to 165 megapixel color
High Dynamic Range (HDR)
Exposure Bracketing 2x, 3x, 5x
Parallax:
Minimized due to co-axial design
Deflection unit
Field of view (vertical/horizontal):
300° / 360°
Step size (vertical/horizontal):
0,009° (40,960 3D-Pixel on 360°) / 0,009° (40,960 3D-Pixel on 360°)
Max. vertical scan speed:
97Hz
Laser (optical transmitter)
Laser class:
Laser class 1
Wavelength:
1550nm
Beam divergence:
0.3mrad (1/e)
Beam diameter at exit:
2.12mm (1/e)
a
Data handling and control
Data storage:
SD, SDHC™, SDXC™; 32GB card
Scanner control:
Via touchscreen display and WLAN
Integrated Sensors
Dual axis compensator:
Performs a leveling of each scan with an accuracy of 19 arcsec valid within ±2°
Height sensor:
The height relative to a fixed point can be detected and added to a scan via electronic barometer
Compass:
The electronic compass gives the scan an orientation.
GNSS:
Integrated GPS & GLONASS
General
Power supply voltage:
19V (external supply)
14.4V (internal battery)
Power consumption:
15W idle, 25W scanning, 80W charging
Battery life:
4.5 hours
Ambient temperature:
5° - 40°C
Humidity:
Non-condensing
Weight:
4.2kg
Size:
230 x 183 x 103mm
Maintenance / calibration:
Annual
Includes:
Faro Focus M70 3D Laser Scanner
Two Faro Battery Packs
Faro battery charger
USB Stick
SD card
Faro Focus M70 Carrying Case
Gitzo Tripod
Also you can check product : USED Faro Focus3D X130 3D Laser Scanner - Calibrated
FEATURES :
Accuracy and range
The Focus Laser Scanner Series provides the highest accuracy and ranges up to 350m by using a combination of the most advanced sensor technologies.
Adaptable and quick
Document any project site or scene, whether indoors or outdoors, in bright sun or complete darkness in minutes. Customize settings to adapt to any scene and capture up to 976,000 points/sec.
IP Rating – Class 54 and extended temperature range
With the sealed design, the Focus devices are certified with the industry-standard Ingress Protection (IP) Rating and classified in class 54 against environmental influences. In addition, there is a scanning challenging temperature conditions due to an extended temperature range.
On-Site compensation
With the on-site compensation functionality, users can verify and adjust the Focus compensation on-site or in the office immediately before scanning, ensuring high-quality scan data and traceable documentation. A comprehensive compensation document is automatically generated.
On-Site registration
During on-site data capture, the laser scanner immediately transmits scanned data wirelessly to FARO SCENE for real-time scan processing and registration, providing efficiency and time savings.
Scan Group feature (Rescanning of Distant Targets)
The Scan Group feature identifies multiple areas to be rescanned with higher resolution to either perform accurate target detection or to capture smaller areas of interest with greater detail.
Retake photos option
No need to redo the entire scans. Select the images to retake the photos in seconds.
Integrated accessory bay
With this future-proof interface, users can connect additional accessories to the scanner, which offers an option for user-specific customization.
Lightweight and small size
Weighs only about 4.2 kg the Focus Laser Scanner is extremely mobile and portable.
HDR photo overlay
With the Focus HDR functionality, challenges like lighting situations will never subtract users’ scan results. Predefined HDR profiles increase the picture quality which is recorded in very bright or dark environments.
Digital hashing function
The automatic digital hashing feature provides encrypted security to all raw scans by hashing data at the time of capture. Use the Scan Verification Tool to ensure that the scan files have not been altered in any way and data is unchanged since first captured.
Status indicator
The visual indicator provides the operator the status of the laser scanner for improved on-site safety.
GENERAL SPECIFICATIONS
Power Supply
19V (external supply), 14.4V (internal battery)
Power Consumption
15W idle, 25W scanning, 80W charging
Battery Service Life
4.5 hours
Temperature
Operating: 5° - 40° C | Extended Operating?: -20° - 55° C | Storage: -10°- 60°C
Ingress Protection (IP) Rating Class
IP54
Humidity Resistance
Non-condensing
Weight
4.2 kg (including battery)
Size/Dimensions
230 x 183 x 103mm
Maintenance / Calibration
Recommended annual
ADDITIONAL PERFORMANCE SPECIFICATIONS
Color Unit
Color Resolution
Up to 165-megapixel color
HDR Camera
Exposure bracketing 2x, 3x, 5x
Parralax
Minimized due to co-axial design
Deflection Unit
Field of View
300°vertical? / 360° horizontal
Step Size
0.009 (40,960 3D-pixel on 360°)
vertical / 0.009 (40,960 3D-pixel
on 360°) horizontal
Max. Scan
Speed 97Hz (vertical)
Laser (Optical Transmitter)
Laser Class
Laser Class 1
Wavelength
1550nm
Beam Divergence
0.3mrad (1/e)
Beam Diameter
at Exit 2.12mm (1/e)
Data Handling and Control)
Data Storage
SDHC, SDXC, 32GB; max. 512GB card
Scanner Control
Via touch screen display and WLAN connection, Access by mobile devices with HTML5
Interface Connection
WLAN
802.11n (150Mbit/s), as access point or client in existing networks
ADDITIONAL FEATURES
Dual Axis Compensator
Performs a leveling of each scan with an accuracy of 19 arcsec valid within ±2
Height Sensor
Via an electronic barometer, the height relative to a fixed point can be detected and added to a scan
Compass
The electronic compass gives the scan an orientation
GNSS
Integrated GPS & GLONASS
On-Site Compensation
Creates current quality report and improves compensation automatically
Accessory Bay*
The accessory bay connects versatile accessories to the scanner
Inverse Mounting
Yes
Real-time, On-site Registration in SCENE
Connects to SCENE, real-time scan processing and registration, overview map
Electronic AutomationInterface
Available as option, only at point of sale
Digital Hash Function
Scans are cryptographically hashed and signed by the scanner
Rescanning of Distant Targets
Defined areas recaptured in higher resolution at a greater distance
Retake Photos
Select individual photographs with unwanted objects and retake them
Also you can check product : USED Faro Focus S70 3D Laser Scanner - Calibrated 2022
The ultra-portable FocusS 150 enables fast, straightforward and ultra-high accurate measurements of objects and buildings. It records architectural façades, complex structures, production and supply facilities, accident sites, and large-volume components delivering realistic and true-to-detail scan results with a range of 150m per scan. This Faro FocusS 150 laser scanner enable to capture fast, straightforward and accurate measurements of complex objects and buildings. The intuitive touch-screen of the FocusS models has been increased in size and clarity to deliver an extraordinary user experience. A built-in 8 mega-pixel, HDR-camera captures detailed imagery easily while providing a natural color overlay to the scan data in extreme lighting conditions. Familiar traits such as light weight, small size and a 4.5-hour battery runtime per charge makes the FocusSLaser Scanner truly mobile for fast, secure and reliable scanning.
The FocusS 150 is a mid-range device offering precise scanning up to 150m. With their sealed design, both models are certified via the industry standard Ingress Protection (IP) Rating, and classified in Class 54 for environmental protection. The devices are built to safeguard against intrusions such as dirt, dust, fog and rain as well as other outdoor elements which typically occur in challenging scanning conditions. An addtion the two laser scanners offer a future-proof interface to connect additional accessories to the scanner and provide a specific on-site compensation routine.
Remote scanning as well as almost limitless scan data sharing via SCENE Webshare Cloud make the laser scanning solution truly mobile.
Features of the new FocusS Laser Scanner
The most recent FocusS series combines all benefits from FARO’s well-known Focus3D Laser Scanners with today’s most innovative
features to perform laser scanning in both indoor and outdoor environments – truly mobile, fast and reliable. Like the latestdevices from the Focus X series they support High Dynamic Range (HDR) photo recording.
What are the functions of HDR?
The HDR laser scanner models record HDR imagery. HDR means high dynamic range and is a technique to capture images with multiple exposure rates and merging them into a single HDR image layer. This HDR image provides additional details in dark or bright areas, which would have been lost in a standard image. These HDR images will be mapped onto the point cloud data generated by the laser scanner.
Main benefits:
Reliable life-like visualization, even under extreme lighting conditions and large distance
Safe and fast as-built data capturing with superior colour detail
Reduced complexity by integrated scanning and imaging workflow for all kinds of scanning tasks
Specs:
Range: 0.6 - 150m
High Dynamic Range (HDR) Photo Recording 2x/3x/5x
Measurement Speed: up to 976,000 points/second
Ranging Error: ± 1mm
Sealed Design - Ingress Protection (IP) Rating Class 54
On-site Compensation
Accessory Bay
Angular Accuracy: 19 arc sec for vertical/horizontal angles
Integrated Colour Camera: Up to 165 mio. pixel
Laser Class: Laser class 1
Weight: 4.2kg
Multi-Sensor: GPS, Compass, Height Sensor, Dual Axis Compensator
Size: 230 x 183 x 103mm
Scanner Control: via Touch Screen Display and WLAN
Complete information of Technical Specification Sheet for the Focus M70 and S70/S150/S350
Includes:
Faro Focus S 150 Laser Scanner: with HDR Photography, GPS, Compass, Altimeter (Barometer), Dual-axis Compensator, WLAN, Accessory Bay, IP Rating 54, On-site Compensation Functionality
Battery Power Block, Battery Power Dock, 90W Power Supply
Optic Cleaning Fluid, Optic Cleaning Tissues
32GB SD Card, SD Card Reader, SD Card Cover
Allen Wrench
Rugged Transport Case
Calibration Certificate
Quick Start Guide
Also you can check product : NEW Faro Focus Core Laser Scanner
Focus Premium Features:
- Up to 350m scanning range, leading to superior area coverage per scan position
- Smartphone-enabled remote control capabilities, limited only by the range of a Wi-Fi network
- Improved wireless workflow with more stable and faster Wi-Fi operation
- On-site registration, the process of combining multiple scans using common overlap, means Scanner control can be executed on either the
app or on the on-board user interface
- Users have easy access to create projects, change scanner settings, manage image resolution, opt for color or black and white scans, group scans through clustering, and add annotations
- Rugged construction and housing can withstand tough day-to-day work
- Integrated high-speed SSD data storage for maximum scan capacity and lighting fast scan processing, plus reliable standard SD card storagefaster project completion and real-time awareness of scan errors or missing data — know before leaving the scene if there are data gaps
Focus Premium 350 Specifications
Range Option
Unambiguity Interval
614 m for up to 0.5 MPts/sec
307 m at 1 MPts/sec
153 m at 2 MPts/sec
White, 90% Reflectivity 0.5 – 350 m
Dark-grey, 10% Reflectivity 0.5 – 150 m
Black, 2% Reflectivity 0.5 – 50 m
Range Noise
White, 90% Reflectivity 0.1 mm @ 10 m, 0.2 mm @ 25 m
Dark-grey, 10% Reflectivity 0.3 mm @ 10 m, 0.4 mm @ 25 m
Black, 2% Reflectivity 0.7 mm @ 10 m, 1.2 mm @ 25 m
Max Speed Up to 2 MPts/sec
3D Accuracy3 2 mm @ 10 m, 3.5 mm @ 25 m
Ranging Error4 ±1 mm
Angular Accuracy5 19 arcsec
LaserHDR Yes
Temperature Range6 Operating: 5 ° to 40 °C, Extended Operating: -10 ° to 55 °C, Storage: -10 ° to 60 °C
Additional Performance Specifications
Color Unit
Color Resolution Up to 266 MPx color
Raw Color
Resolution 867 MPx
HDR Camera 13 MPx - 2x, 3x, 5x brackets
Parallax Minimized due to co-axial design
Deflection Unit
Field of View 300° vertical8 / 360° horizontal
Step Size
0.009° (40,960 Pts on 360°) vertical / 0.009° (40,960 Pts on 360°) horizontal
Max. Scan Speed 97 Hz (vertical)
Laser (Optical Transmitter)
Laser Class Laser Class 1
Wavelength 1553.5 nm
Beam Divergence 0.3 mrad (1/e)
Beam Diameter
at Exit 2.12 mm (1/e)
Data Handling and Control
Data Storage
SATA 3.0 SSD 128 GB and SDXC V30 64 GB SD Card; SD3.0, UHS-I / SDXC™ / SDHC™, max. 512 GB
Scanner Control
Via touch screen display and WLAN connection, Control by FARO Stream App (iOS & Android) or mobile devices with HTML5
Interface Connection
WLAN
IEEE 802.11 ac/a/b/g/n 2x2
MIMO, as access point or client in
existing networks (2.4 and 5 GHz)
USB
USB 3 port
Additional Features
Dual Axis Compensator Performs a leveling of each scan with an accuracy of 19 arcsec valid within ±2°
Height Sensor Via an electronic barometer, the height relative to a fixed point can be detected and added to a scan
Compass9 The electronic compass gives the scan an orientation
GNSS Integrated GPS & GLONASS
On-Site Compensation Creates current quality report and improves compensation automatically
Accessory Bay The accessory bay connects versatile accessories
to the scanner
Inverse Mounting Yes
Real-time, On-site Registration Stream App real-time scan streaming, registration, overview map and Sphere cloud upload
Electronic Automation Interface Available as option, only at point of sale
Digital Hash Function Scans are cryptographically hashed and signedby the scanner
Rescanning of Distant Targets Defined areas recaptured in higher resolution at a greater distance
Retake Photos Select individual photographs with unwanted objects and retake them
General Specifications
Power Supply 19 V (external supply), 14.4 V (internal battery)
Typical Power Consumption 19 W idle, 32 W scanning, 72 W charging
Typical Battery Operation Time About 4 hours
Typical Scan Time from start until
the scanner can be moved7
Gray scale < 1 min | HDR Colored < 1:15 |
Colored Flash Scan < 30 seconds10
Ingress Protection (IP)
Rating Class 54
Humidity Non-condensing
Weight 4.4 kg (including battery)
Size/Dimensions 230 x 183 x 103 mm
Calibration Recommended annually
Manufacturer Warranty 2 years
Includes :
Faro Focus Premium Laser scanner
Power dock battery charger
Power supply unit
Power block battery (ACCS-PWR-0014)
Scanner transport and carrying case
Mirror cleaning liquid for optics
SD card reader (An SD card is already inserted in the scanner.)
Status indicator
4mm hex key
Quick release
Quick Start Guide and Safety Manual
AC power cable
Also you can check product : NEW Faro Focus S150 Laser Scanner
The Ultimate in 3D Data Capture
Building on our history of accuracy and reliability, the new FARO® Focus Premium Laser Scanner is the fastest, most accurate and most data-sharing-enabled scanner on the market to date, featuring entirely new components with a proven design.
Up to 50% Faster Scan Times
About 1 minute to complete a typical scan, in combination with the optional FARO PanoCam upgrade, even in color.
Two-Year Warranty
Competitive service means maximizing the life of this product while reducing the total cost of ownership throughout the device’s lifespan. Two years allows for maximum flexibility and the piece of mind knowing that any defective parts will be replaced.
Super-High Color Resolution
The latest color camera technology enables the Focus Premium to capture scans with up to 266 megapixel color information.
Hybrid Reality Capture, powered by Flash Technology
The optional Flash extension provides you with fully colorized scan data in less than 30 seconds per station whenever an extra boost of productivity is needed. This patent pending technology will save you up to an additional 50% of on-site time without compromising data quality and accuracy.
On Closer Inspection
Focus Premium provides exceptional capturing efficiency, data quality and accuracy for professional
applications across the construction, public safety, operations & maintenance and manufacturing
markets, while offering data quality at faster scan speeds (up to 1 minute per scan) reducing onsite
scanning time by up to 50%. Meanwhile, faster loading and system response yields greater data
management efficiency when paired with the new FARO Stream mobile app and uploaded to
the new FARO Sphere cloud-based collaboration platform.
Focus Premium Features:
Up to 350m scanning range, leading to superior area coverage per scan position
Smartphone-enabled remote control capabilities, limited only by the range of a Wi-Fi network
Improved wireless workflow with more stable and faster Wi-Fi operation
On-site registration, the process of combining multiple scans using common overlap, means faster project completion and real-time awareness of scan errors or missing data
Seamless connectivity with Stream and Sphere
Scanner control can be executed on either the app or on the actual Focus
Users have easy access to create projects,change scanner settings, manage image resolution, opt for color or black and white scans, group scans through clustering, and add annotations
Rugged construction and housing can withstand the tough day-to-day work
Integrated high-speed SSD data storage for maximum scan capacity and lighting fast
scan processing
SPECS :
Range Option
Unambiguity Interval
614 m for up to 0.5 MPts/sec
307 m at 1 MPts/sec
153 m at 2 MPts/sec
White, 90% Reflectivity 0.5 – 150 m
Dark-grey, 10% Reflectivity 0.5 – 150 m
Black, 2% Reflectivity 0.5 – 50 m
Additional Performance Specifications
Color Unit
Color Resolution Up to 266 MPx color
Raw Color
Resolution 867 MPx
HDR Camera 13 MPx - 2x, 3x, 5x brackets
Parallax Minimized due to co-axial design
Deflection Unit
Field of View 300° vertical8 / 360° horizontal
Step Size
0.009° (40,960 Pts on 360°) vertical / 0.009° (40,960 Pts on 360°) horizontal
Max. Scan Speed 97 Hz (vertical)
Laser (Optical Transmitter)
Laser Class Laser Class 1
Wavelength 1553.5 nm
Beam Divergence 0.3 mrad (1/e)
Beam Diameter
at Exit 2.12 mm (1/e)
Data Handling and Control
Data Storage
SATA 3.0 SSD 128 GB and SDXC V30 64 GB SD Card; SD3.0, UHS-I / SDXC™ / SDHC™, max. 512 GB
Scanner Control
Via touch screen display and WLAN connection, Control by FARO Stream App (iOS & Android) or mobile devices with HTML5
Interface Connection
WLAN
IEEE 802.11 ac/a/b/g/n 2x2
MIMO, as access point or client in
existing networks (2.4 and 5 GHz)
USB
USB 3 port
Additional Features
Dual Axis Compensator Performs a leveling of each scan with an accuracy of 19 arcsec valid within ±2°
Height Sensor Via an electronic barometer, the height relative to a fixed point can be detected and added to a scan
Compass9 The electronic compass gives the scan an orientation
GNSS Integrated GPS & GLONASS
On-Site Compensation Creates current quality report and improves compensation automatically
Accessory Bay The accessory bay connects versatile accessories
to the scanner
Inverse Mounting Yes
Real-time, On-site Registration Stream App real-time scan streaming, registration, overview map and Sphere cloud upload
Electronic Automation Interface Available as option, only at point of sale
Digital Hash Function Scans are cryptographically hashed and signedby the scanner
Rescanning of Distant Targets Defined areas recaptured in higher resolution at a greater distance
Retake Photos Select individual photographs with unwanted objects and retake them
General Specifications
Power Supply 19 V (external supply), 14.4 V (internal battery)
Typical Power Consumption 19 W idle, 32 W scanning, 72 W charging
Typical Battery Operation Time About 4 hours
Typical Scan Time from start until
the scanner can be moved7
Gray scale < 1 min | HDR Colored < 1:15 |
Colored Flash Scan < 30 seconds10
Ingress Protection (IP)
Rating Class 54
Humidity Non-condensing
Weight 4.4 kg (including battery)
Size/Dimensions 230 x 183 x 103 mm
Calibration Recommended annually
Manufacturer Warranty 2 years
Includes :
Faro Focus Premium Laser scanner
Power dock battery charger
Power supply unit
Power block battery (ACCS-PWR-0014)
Scanner transport and carrying case
Mirror cleaning liquid for optics
SD card reader (An SD card is already inserted in the scanner.)
Status indicator
4mm hex key
Quick release
Quick Start Guide and Safety Manual
AC power cable
Also you can check product : NEW Faro Focus Premium 350 Laser Scanner
This FARO Freestyle 2 compact device is a game-changer for the public safety arena given its remarkable degree of photorealism 3d reality data capture. As an advanced handheld 3D forensic scanner, FARO Freestyle 2 is ideal for investigators and reconstructionists who require fast and complete scene documentation, Freestyle 2 provides immediate real-time visualizations with photorealistic reality capture capabilities. The result is unmatched confidence that what is captured is accurate while offering unparalleled access to even the most confined spaces. Designed for normally illuminated interiors and outdoor spaces (10,000-45,000 lux) including overcast conditions, Freestyle 2 is also capable of generating usable data even in complete darkness. Thus, documenting scenes has never been easier. In addition, the device’s one-hand operation leaves the operator’s other hand free to open doors, balance or brace themself against objects for a better, more stable capturing angle and provides the ultimate on-scene flexibility to reach in, under, and around objects. Plus, haptic feedback alerts the operator when adjustments are required to the user’s scanning technique to ensure the highest quality data is always being captured.
FEATURES
- Real-Time Visualization: Display lets you view what you capture as you scan
Wide-Range of Scanning Distances:
- Captured 3D Points starts at 0.4 m
- Can be set to a maximum of 10 m
- Capture in Variety of Lighting Conditions
- Designed for normally illuminated interiors and outdoors, including in overcast conditions
- Even provides usable data in complete darkness
- One-Hand Operation : Lightweight with no bulky tablet or long cables
- Guided Scanning:
- Haptic feedback alerts operator when adjustments need to be made to the users scanning technique
- Proprietary tracking engine enables users to make natural movements while scanning
- On-Site Compensation:
- White-balancing, post-processing can be done at the scene
- No annual calibration required
- Integrated Training: Live display of data quality with integrated training videos, and tutorials
BENEFITS
Ultimate Flexibility
Freestyle 2 is portable, without the need for bulky computers
Self-contained unit gives the freedom to scan around objects or inside spaces
Save Time
Scan scenes and objects without data voids in minutes
Captures data easily and in more detail in less time
Photorealistic Results: Get high-quality, colored, 3D data with up to 0.5 mm accuracy
Confidence in What you Capture: See a display of data as you capture to ensure you are getting what you need
Easy-to-learn & Easy-to-Use : Modern user interface, proprietary tracking algorithms, integrated video tutorials
SPECS :
Range 0.4 - 5 m (up to 10 m with limited data quality)
Identifiable feature Up to 0.2 m
Long range accuracy 0.5 mm at 1 m distance
5 mm at 5 m distance
15 mm at 10 m distance
Single image point density Up to 45,000 points/m² in 0.5 m distance
Up to 10,500 points/m² in 1 m distance
Acquisition Rate Up to 220,000 points/s, point cloud density increases with time
Typical Noise 0.3 mm @ 0.4 m distance
0.75 mm @ 1 m distance
10 mm @ 3 m distance
35 mm @ 5 m distance
100 mm @ 10 m distance
Lighting conditions Full daylight, 10,000-45,000 lux (reduced performance in direct sunlight)
Light source Integrated LED flash
Scan volume 39.5 m³ @ max range 5 m
Typical field of view (HxW) 420 mm x 550 mm @ 0.5 m
930 mm x 1170 mm @ 1 m
1800 mm x 2160 mm @ 2 m
2740 mm x 3160 mm @ 3 m
3600 mm x 4160 mm @ 4 m
4470 mm x 5150 mm @ 5 m
Exposure time 0.1 ms - 7 ms (autoexposure)
Texture color 24 bit
Dimensions 285 mm x 256 mm x 130 mm
Connectivity HDMI, USB 3.0, WiFi
Weight 1.48 kg
IP rating IP 52
Compensation Onsite - with supplied compensation plate
Op temperature range 0 - 40° C
Op humidity range Non-condensin
Eye Safety Class 1 Laser
Wavelength 798-816 nm
INCLUDED :
FARO Freestyle 2
FARO Freestyle 2 Mobile PC fully functional Windows computer with the latest version of SCENE Capture
Android smartphone Samsung A72
Magnet kit for smartphone
Belt and shoulder strap
Onsite calibration plate
Battery, Charger
USB cable, High speed USB stick
Targets kit, Cleaning kit
Quick guide
Rugged case
2 Year FARO Warranty includes Calibration, Certification, Repair parts, Labor and Shipping from FARO Service Center
Also you can check product : NEW Faro Focus Premium 150 Laser Scanner
Focus Core enables fast colorized 3D scans and delivers a cost-competitive solution for construction, operations and public safety professionals eager to strike the optimal balance between scanning accuracy and speed, reducing time spent on site or on scene, while eliminating materials waste and personnel bottlenecks.
Through an optional subscription to the FARO Stream mobile app for smart devices, Core users will benefit from real-time on-site pre-registration, which will allow faster project completion and a reduced need to return to a jobsite multiple times to capture additional scans.
Focus Core is also compatible with Sphere, the company’s cloud-based SaaS platform, which will enable enhanced collaboration of global teams, fast delivery of as-built data, and the ability to make better informed decisions in less time.
Features
Optimized scanning range
-70-meter range with a distance accuracy of 2mm
Fast color capture
-1-minute internal SDR per scan, or
-2.5 min internal HDR per scan
-Even faster color capture with the optional panoramic camera add-on
Color resolution ideal for fast on-scene reality capture
-165 megapixels
Pre-registration with Stream (optional)
-Upload on-site pre-registered scan data via the Stream Mobile App
-Share information with project stakeholders anywhere in
the world via FARO Sphere
Faster loading and system response
-Greater data management efficiency
-New high performance electronics provide a smooth user experience and fluent on-site operation
Smartphone-enabled
-Remote control capabilities with the optional Stream support
-Fast Wi-Fi operation
Benefits
Multiple application use
-Construction, Public Safety and Operations offering data quality at faster scan speeds
-Ideal for public safety agencies looking to improve onscene evidence capture quality and efficiency
Reduce Rework and Material Waste
-Know the as-built condition of your project and ensure your designs fit the first time
-Monitor construction progress regularly and frequently in 3D helps you identify issues before they become costly and delay your schedule
Eliminate error-prone traditional measurement methods
-The Focus Core allows the ability to complete on-scene (forensic investigation tasks) and on-site (jobsite) data collection, faster, and to do so with greater accuracy, confident that the data is captured correctly, and not requiring multiple site/scene visits.
Confidence to leave the site with complete and useful data
-Make data accessible to project stakeholders early on with Stream option and the FARO Sphere cloud platform
-Two-year manufacturer warranty means maximizing the life of this product with servicing while reducing the total cost of ownership throughout the device’s lifespan.
Performance Specifications
Range
White, 90% Reflectivity 0.5 – 70 m
Dark-grey, 10% Reflectivity 0.5 – 70 m
Black, 2% Reflectivity 0.5 – 50 m
Range Noise1,2
White, 90% Reflectivity 0.4 mm @ 10 m, 0.5 mm @ 25 m
Dark-grey, 10% Reflectivity 1.0 mm @ 10 m, 1.5 mm @ 25 m
Black, 2% Reflectivity 3.0 mm @ 10 m, 5.0 mm @ 25 m
Max Speed Up to 0.5 MPts/sec
3D Accuracy3 3 mm @10m, 4 mm @25m
Ranging Error4 ±2 mm
Angular Accuracy5 19 arcsec
LaserHDR Yes
Temperature Range6 Operating: 5° - 40° C | Extended Operating: -10° - 55° C | Storage: -10°- 60°C
Additional Performance Specifications
Color Unit
Color Resolution Up to 165 MPx color
Raw Color Resolution 527 MPx
HDR Camera 8 MPx - 2x, 3x, 5x brackets
Parallax Minimized due to co-axial design
Deflection Unit
Field of View 300° vertical8 / 360° horizontal
Step Size
0.009° (40,960 Pts on 360°) vertical /
0.009° (40,960 Pts on 360°) horizontal
Max. Scan Speed 97 Hz (vertical)
Laser (Optical Transmitter)
Laser Class Laser Class 1
Wavelength 1553.5 nm
Beam Divergence 0.3 mrad (1/e)
Beam Diameter at Exit 2.12 mm (1/e)
Data Handling and Control
Data Storage
SATA 3.0 SSD 128 GB
and SDXC™ V30 64 GB SD Card; SD3.0,
UHS-I / SDXC™ / SDHC™, max. 512 GB
Scanner Control
Via touch screen display and WLAN
connection, Control by FARO Stream
(optional) App (iOS & Android) or
mobile devices with HTML5
Interface Connection
WLAN
IEEE 802.11 ac/a/b/g/n 2x2 MIMO,
as access point or client in existing
networks (2.4 and 5 GHz)
USB
USB 3 port
Additional Features
Dual Axis Compensator Performs a leveling of each scan with an accuracy of 19 arcsec valid within ±2°
Height Sensor Via an electronic barometer, the height relative to a fixed point can be detected and added to a scan
Compass9 The electronic compass gives the scan an orientation
GNSS Integrated GPS & GLONASS
Accessory Bay The accessory bay connects versatile accessories to the scanner
Inverse Mounting Yes
Real-time, On-site Registration Stream App (optional) real-time scan streaming, registration, overview map and Sphere cloud upload
Digital Hash Function Scans are cryptographically hashed and signed by the scanner
Rescanning of Distant Targets Defined areas recaptured in higher resolution at a greater distance
Retake Photos Select individual photographs with unwanted objects and retake them
General Specifications
Power Supply 19 V (external supply), 14.4 V (internal battery)
Typical Power Consumption 19 W idle, 32 W scanning, 72 W charging
Typical Battery Operation Time About 4 hours
Typical Scan Time7 About 1 min
Ingress Protection (IP) Rating Class 54
Humidity Non-condensing
Weight 4.4 kg (including battery)
Size/Dimensions 230 x 183 x 103 mm
Calibration Recommended annually
Manufacturer Warranty 2 years
Also you can check product : NEW Faro Focus S350 3D Laser Scanner
Spesification :
Ranging Unit
Unambiguity interval: 153.49m (503.58ft)
Range Focus3D 1201: 0.6m – 120m indoor or outdoor with low ambient light and normal incidence to a 90% re?ective surface
Range Focus3D 20: 0.6m – 20m at normal incidence on >10% matte re?ective surface*
Measurement speed: 122,000 / 244,000 / 488,000 / 976,000 points/sec
Ranging error2: ±2mm
Color Unit
Resolution: Up to 70 megapixel color
Dynamic color feature: Automatic adaption of brightness
Detection unit
Vertical feld of view (vertical/horizontal): 305° / 360°
Step size (vertical/horizontal): 0.009° (40,960 3D pixels on 360°) / 0.009° (40,960 3D pixels on 360°)
Max. vertical scan speed: 5,820rpm or 97Hz
Laser (Optical transmitter)
Laser power (cw Ø): 20mW (Laser class 3R)
Wavelength: 905nm
Beam divergence: Typical 0.19mrad (0.011°)
Beam diameter at exit: 3.0mm, circular
Data handling and control
Data storage: SD, SDHC™, SDXC™; 32GB card included
Scanner control: Via touch-screen display
New WiFi(WLAN) access: Remote control, Scan Visualization and download are possible on mobile devices with Flash
Multi-Sensor
Dual axis compensator: Levels each scan with an accuracy of 0.015° and a range of ±5°
Height sensor: Detects the height relative to a fxed point via an electronic barometer and adds it to the scan
Compass: Electronic compass gives the scan an orientation. A calibration feature is included
Hardware Spesification
Power supply voltage: 19V (external supply), 14.4V (internal battery) Cable connector: Located in scanner mount
Power consumption: 40W and 80W respectively (while battery charges) Weight: 5.0kg
Battery life: Up to 5 hours Size: 240x200x100mm3
Ambient temperature: 5° – 40°C Maintenance calibration: Annual
Humidity: Non-condensing Parallax-free: Yes
Includes :
Faro Focus3D Multi Sensor 120 Laser Scanner with compass, altimeter (barometer), dual-axis compensator and WLAN
PowerBlock Battery and extra Battery, Charger
32 GB SD card, SD card reader, Case for the SD card
Faro SCENE License Network License
1x case with reference spheres
Gitzo Carbon Fibre Tripod
Pair of laser protection glasses
Solid carrying case
Quick release
Also you can check product : USED Faro Focus S350 Terrestrial 3D Laser Scanner
- 1
